Barred Spiral Galaxy NGC 2146
Supernova 2005V
taken at 2:45 UT on Feb 6, 2005. A 10 minute exposure with SBIG STL-1301E
CCD camera thru an Optical Guidance Systems 20-inch F/8.1 Telescope.
Field of view = about 12x13 arc minutes with North at the top.
A 10
minute exposure with SBIG ST-6 CCD camera thru an Optical Guidance Systems
20-inch F/8.1 Telescope. Field of view = about 5x7 arc minutes with North at the top.
Supernova 2005V:
o
Discovered: January
30th, 2005 by Nuclear Supernova Search.
o
Magnitude at discovery: 13.8, K-band (IR)
o
Type: Ib
Follow this Link to a NASA Web site on supernovas. It has a very nice animation and a description of what these objects are.
Quote from Dreyer's New General Catalog (NGC):
"Pretty bright, 2 arc minutes long, little extended."
NGC 2146 is a relatively nearby peculiar Barred Spiral Galaxy in the Constellation of Camelopardalis. It is a nearly edge-on disturbed starburst galaxy (i.e. enhanced star-forming activity). It has a peculiar large nuclear bulge with many irregular absorption markings and two main smooth spiral arms, one with a dark lane. The extremely broad spiral arms appear asymmetric, and probably lie in different planes. Thus NGC 2146 could have a very warped disk, twisted through an angle of about 45 degrees.
This galaxy is associated with radio source 4C 78.06 and several infrared sources, plus its optical spectrum shows bright hydrogen alpha lines. Hutchings et al. (1990) suggested that NGC 2146 is in the final stages of a collision and merger and found no evidence of an active nucleus. It may be interacting with NGC 2146A which lies 18 arc minutes away.
- NGC 2146
- Magnitude: 11.1
- Constellation: Camelopardalis
- RA: 06h 18m 40.1s
- Dec: +78° 21' 19" Epoch 2000
- Size (mins): 6.0' x 3.4'
- Distance: 47 Million Light Years
- Diameter: 82,000 Light Years
- Classification:
SB(s)ab, pec, H-II
Barred Spiral, S-shaped, peculiar, starburst
Click below to
George Normandin, KAS
February 7th, 2005
